Gilera Fuoco 500 - Taillight Assy.

- Remove the two shield back plate lower screws.
- Remove the external temperature sensor con-
nection.
See also
spoiler
Legshield
Taillight assy.
- Remove the side fairings.
- Remove the handgrips.
- Undo the screw indicated in the figure.
- Undo the two screws connecting it to the helmet
compartment.
- Disconnect the connectors and remove the sup-
port.
- Undo the three screws and remove the light unit.
Fuoco 500 i.e. Chassis
CHAS - 9
