Name Torque in Nm

Fixing screws for tilt locking disc section 20 ÷ 25

Geared motor and Suspension locking system

Select the SYSTEM RESET option from the main

menu

Turn the key switch to ON

Select the LOWER STOP SEARCH option from

the SYSTEM RESET menu

WAIT

PROCEDURE IN PROGRESS

Suspensions Fuoco 500 i.e.

SUSP - 16
