Front suspension

FRONT SUSPENSION

Code Action Duration

1 003010 Front suspension - Service

2 003111 Side steering tube - replace-

ment

3 003038 Front wheel axle - Remov.

and Refitt.

4 003040 Front wheel bearings - Re-

placement

5 003107 Sliding stems - replacement

6 003113 Front shock absorber - re-

placement

Time Fuoco 500 i.e.

TIME - 42
