Legshield spoiler

FRONT SHIELD

Code Action Duration

1 004021 Shield upper section - Re-

placement

2 004022 Shield lower section - Re-

placement

3 004020 Headlight rim - Replacement

4 004085 Fairing (1) - Replacement

5 004064 Front shield - Replacement

Fuoco 500 i.e. Time

TIME - 21
