- Remove the helmet compartment.
spoiler
- Remove the GILERA clip-on badge paying at-
tention not to spoil the paint.
- Undo the screw underneath.
- Undo the four screws indicated.
Fuel tank
Remove the chassis central cover.
Remove the footrest.
Remove the three tank retainers.
Fuoco 500 i.e. Chassis
CHAS - 13
