Gilera Fuoco 500 - Components Arrangement

51. Injector
52. Fuel pump
53. Revolution sensor
54. HV coil
55. Injection ECU
56. Immobilizer aerial
57. Brake calliper sensor
58. Diagnosis connector
59. Coolant temperature sensor
60. Lambda probe
61. MIU control unit power device
62. Electric fan remote control
63. Electric fan
64. Geared motor
Key
Ar: Orange Az: Sky blue Bi: White Bl: Blue Gi: Yellow Gr:Grey
Ma:Brown Ne: Black Ro: Pink Rs: Red Ve: Green Vi: Purple
Components arrangement
Electrical system Fuoco 500 i.e.
ELE SYS - 4
