Gilera Fuoco 500 - Upper Shock Absorber Clamp

Name Torque in Nm
Lower fitting for shock absorber sliding locking
clamp pipes
20 ÷ 25
Upper fitting for shock absorber sliding locking
clamp pipes
20 ÷ 25
REAR SUSPENSION
Name Torque in Nm
Upper shock absorber clamp 33 ÷ 41
Shock absorber lower clamp 33 ÷ 41
Shock absorber-crankcase attachment bracket 20 ÷ 25
Rear wheel axle 104 ÷ 126
Muffler arm clamping screws 27 ÷ 30
FRONT BRAKE
Name Torque in Nm
Calliper coupling screw 22 ÷ 27
Oil bleed screw 8÷12
Disc tightening screw (°) 5 - 6
Brake fluid pump - hose fitting 16 ÷ 20
Brake fluid hose-calliper fitting 20 ÷ 25
Screw tightening calliper to the support 20 ÷ 25
Calliper upper pipe fitting 20 ÷ 25
REAR BRAKE
Name Torque in Nm
Oil bleed screw 12÷16
Rear brake disc screws(°) 5 ÷ 6.5
Rear brake calliper-pipe fitting 20 ÷ 25
Rigid / flexible pipe fitting 13 ÷ 18
Rear brake pump-pipe fitting 16 ÷ 20
Rear brake calliper fixing screws 20 ÷ 25
pad fastening pin screws 20 ÷ 25
REAR BRAKE
Product Description Specifications
(°) Loctite 243 Medium strength threadlock Apply LOCTITE 243 medium
strength threadlock
MUFFLER
Name Torque in Nm
Muffler heat guard fixing screw 4 ÷ 5
Screw for fixing muffler to the support arm 20 ÷ 25
Lambda probe clamp on exhaust manifold 40 ÷ 50
Exhaust manifold-muffler joint clamp 12 ÷ 13
Manifold - muffler diaphragm tightening clamp 16 ÷ 18
LUBRICATION
Name Torque in Nm
Oil pump cover screws 0.7 ÷ 0.9
Screws fixing oil pump to the crankcase 5 - 6
Fuoco 500 i.e. Characteristics
CHAR - 7
