1. Parking electronic control unit
10. Main fuses
11. Key switch contacts
12. Auxiliary fuses
13. Key switch contacts
15. Battery
26. Turn indicator switch
27. Turn signal command device
28. Hazard button
29. Light switch
30. Headlight remote control
32. License plate light bulb
33. Rear left turn indicator
34. Rear light
A. Tail light bulbs
35. Rear right turn indicator
36. Front left turn indicator
37. Headlight
A. Left low-beam light bulb
B. Left high-beam light bulb
C. Tail light bulb
D. Right low-beam light bulb
E. Right high-beam light bulb
38. Front right turn indicator
43. Instrument panel
Checks and inspections
This section is devoted to the checks on the electrical system components.
Fuoco 500 i.e. Electrical system
ELE SYS - 15
