Air cleaner

DEPURATORE ARIA

Code Action Duration

1 001015 Air filter box - Replacement

2 001014 Air filter - Replacement /

cleaning

3 004122 Cleaner / Throttle body union

- Replacement

4 001027 Body / air cleaner union - Re-

placement

Time Fuoco 500 i.e.

TIME - 18
