Rocker arms support assy.

ROCKING LEVER SUPPORT UNIT

Code Action Duration

1 001044 Camshaft - Replacement

2 001148 Rocking lever valve - Re-

placement

3 001169 Decompressor - Replace-

ment

Fuoco 500 i.e. Time

TIME - 7
