Mudguard

MUDGUARDS

Code Action Duration

1 007015 Radiator air intake - Replace-

ment

2 004009 Rear mudguard - Replace-

ment

3 004181 Lower cover - Replacement

4 004184 Front mudguard support - re-

placement

5 004002 Front mudguard - Replace-

ment

Time Fuoco 500 i.e.

TIME - 24
