Remove the three fixing screws of the electric mo-
tor.
It is important to mark the direction of the electric
motor position in order to refit it correctly.
Remove the four screws indicated in the figure,
remove the flexible transmission supporting brack-
et, separate the two crankcase halves, if neces-
sary, use a rubber mallet to hit the flexible
transmission lever in order to separate the two
crankcases.
Electrical devices test
PRESSURE SWITCH
1: PRESSURE SWITCH
2: HORN REMOTE CONTROL
Fuoco 500 i.e. Suspensions
SUSP - 29
