SPECIFIC TOOLS CORRECT

Stores code Description

001330Y Tool for fitting steering seats

001467Y002 Driver for OD 73 mm bearing

001467Y006 Extraction pliers for 20 mm bear-

ings

001467Y007 Driver for OD 54 mm bearing

001467Y008 Extraction pliers for ø 17 mm

bearings

001467Y014 Extraction pliers for ø 15 mm

bearings

Tooling Fuoco 500 i.e.

TOOL - 2
