Knee-guard
- Remove the front shield.
- Remove the handlebar covers.
- Remove the spoiler.
- Remove the two central screws and the coolant
cap cover screw.
- Remove the expansion tank fixing screw and the
frame from the instrument panel and manually re-
lease the unions with the shield back plate.
- Unhook the instrument panel wiring.
- Remove the six screws and the cable guide strap
in the front part of the shield back plate.
Fuoco 500 i.e. Chassis
CHAS - 7
