Handles and top side fairings
- Remove the side fairings.
- Undo the seven screws fixing the turn indicator
arrows.
- Disconnect the license plate light connector.
- Undo the three screws indicated at both sides
and remove the handgrip clamp.
Radiator cover
- Remove the front shield.
- Remove the headlight assembly.
- Disconnect the turn indicators wirings.
- Undo the two screws indicated.
Fuoco 500 i.e. Chassis
CHAS - 15
