Cylinder head assy.

GRUPPO TESTA

Code Action Duration

1 001045 Valves - Replacement

2 001049 Valves - Adjustments

3 001056 Head gasket - Replacement

4 001126 Head - Replacement

5 001083 Thermistor - Replacement

6 007012 Coolant bleed valve - Re-

placement

7 001057 Thermostat - Replacement

Time Fuoco 500 i.e.

TIME - 6
