Gilera Fuoco 500 - Front Handlebar Cover; Headlight Assy.

Front handlebar cover
- Unscrew the six screws and remove the upper
cap and the rear handlebar cover.
- Unscrew the two screws fixing the handlebar to
remove the front part of the handlebar cover.
Headlight assy.
- Remove the front shield.
- Unscrew the screw of the tail light support.
- Disconnect the electrical terminals and remove
the support.
Fuoco 500 i.e. Chassis
CHAS - 3
