Crankcase

CRANKCASE

Code Action Duration

1 001100 Oil seal, clutch side - Re-

placement

2 001133 Engine crankcase- Replace-

ment

3 001153 Half crankcase gasket - Re-

placement

Fuoco 500 i.e. Time

TIME - 3
