This section is devoted to the time necessary to carry out repairs.

For each operation, the description, code and time envisages are specified.

Engine

ENGINE

Code Action Duration

1 001001 Engine to chassis - Replace-

ment

Time Fuoco 500 i.e.

TIME - 2
