Flywheel magneto

VOLANO MAGNETE

Code Action Duration

1 001173 Rotor - replace

2 001067 Stator - Replacement

3 001058 Flywheel - Replacement

4 001104 Start-up freewheel - Replace-

ment

Fuoco 500 i.e. Time

TIME - 15
