Frame

CHASSIS

Code Action Duration

1 004146 Front frame - Replacement

2 004001 Frame - replace

3 004147 footboard support bracket

one side - Replacement

4 004143 Footrest support - replace

5 004116 Rear frame - Replacement

6 004148 footboard support bracket

two sides - Replacement

7 902003 Supporto fanale anteriore -

Sostituzione

Fuoco 500 i.e. Time

TIME - 19
