Electric start

AVVIAMENTO

Code Action Duration

1 001017 Start-up pinion - Replace-

ment

2 001020 Starter motor - Replacement

3 001151 Start-up driven gearing - Re-

placement

Fuoco 500 i.e. Time

TIME - 37
