7 - Replace the oil minimum pressure switch.
8 - If pressure lower than 1.3 - 1.5 bar is measured.
AHEAD go to 9
9 - Replace the oil filter and repeat the pressure check with oil at 80°C.
YES go to 10 NO go to 13
10 - The failure was fixed.
It is recommended to respect the suggested number of kilometres covered.
11 - Check and restore the electrical system.
12 - If pressure lower than 4 bar is measured.
AHEAD go to 9
13 - Remove the flywheel cover and check the by-pass and the cover sealing gasket efficiency towards
the case internal side, as described in the "Flywheel cover" chapter.
YES go to 14 NO go to 15
14 - Check whether there is an irregular clearance on the crankshaft:
- axial clearance (see the "Crankcase and crankshaft" chapter)
- radial clearance, especially in the direction of the cylinder axis
- clearance according to the direction of rotation with the connecting rod in quadrature
YES go to 16 NO go to 17
15 - Replace the faulty components ("Flywheel cover" chapter).
16 - Overhaul the engine ("Crankcase and crankshaft" chapter).
17 - Open the engine crankcase and remove the oil pump, as described in the "Crankcase and crank-
shaft" chapter.
- Check the oil pump as described in the following pages.
- Check that the cooling nozzle and the timing feeding jet are properly installed.
- Visually inspect the crankshaft couplings and their size ("Crankcase and crankshaft" chapter).
N.B.
ANY FAILURES OF THE COUPLINGS AND OF THE TIMING COMPONENTS CANNOT BE DE-
TECTED BY THE INSPECTION OF THE LUBRICATION PRESSURE. THE FAILURES MAY BE-
COME EVIDENT BY AN INCREASE OF NOISE.
N.B.
IN CASE OF IRREGULAR PRESSURE ON THE BASE, CARRY OUT A VISUAL AND DIMENSIONAL
INSPECTION OF THE TIMING COMPONENTS (SEE THERMAL UNIT AND TIMING SYSTEM CHAP-
TER).
Oil pressure check
1 - In case of oil leaks from the oil filter or from the flywheel cover coupling gasket, check the lubrication
pressure.
AHEAD go to 2
2 - Install the special tool.
Specific tooling
Engine Fuoco 500 i.e.
ENG - 98
