Driven pulley

DRIVEN PULLEY

Code Action Duration

1 001022 Clutch - Replacement

2 001012 Driven pulley - Overhaul

3 001110 Driven pulley - Replacement

4 001155 Clutch bell housing - Re-

placement

Time Fuoco 500 i.e.

TIME - 10
