Oil pump

POMPA OLIO

Code Action Duration

1 001042 Oil pump - overhaul

2 001051 Belt/ Timing chain - Replace-

ment

3 001112 Oil pump - change

4 001125 Chain guide pads - change

Fuoco 500 i.e. Time

TIME - 11
