Gilera Fuoco 500 - Removing the Intake Manifold; Removing the Rocker-Arms Cover; Removing the Timing System Drive

Removing the intake manifold
- Remove the 3 mounting screws.
- Remove the intake manifold unit.
Removing the rocker-arms cover
- Loosen the 6 special screws with stop and the
relevant rubber gaskets.
- Remove the tappet cover with relevant gasket.
Removing the timing system drive
- Turn the engine to close the intake valves.
Fuoco 500 i.e. Engine
ENG - 49
