Gilera Fuoco 500 - Overhaul Data; Assembly Clearances; Cylinder - Piston Assy.

Name Torque in Nm
Gear mounting on crankshaft screws 10 -12
Bulkhead screws for oil pump housing cover 8 - 10
COOLING
Name Torque in Nm
Water pump rotor cover 3 ÷ 4
Thermostat cover screws 3 ÷ 4
Bleed screw: 3
FINAL REDUCTION
Name Torque in Nm
Rear hub cover screws 24 ÷ 27
ENGINE ASSEMBLY
Name Torque in Nm
starter motor retainers 11 - 13
Overhaul data
Assembly clearances
Cylinder - piston assy.
Fuoco 500 i.e. Characteristics
CHAR - 9
