Gilera Fuoco 500 - Page 326

- Undo the two screws fixing it to the frame.
- Undo the two screws fixing it to the upper part of
the shield back plate.
- Disconnect the assembly connectors at both
sides and remove the support.
- Undo the ten screws fixing it to the support and
remove the headlight assemblies.
Chassis Fuoco 500 i.e.
CHAS - 4
