20. Stop button on rear brake
21. Stop button on front brake
22. Starter button
23. Saddle opening receiver
24. Wiring for antitheft device
25. Helmet compartment light switch
26. Turn indicator switch
27. Turn signal command device
28. Hazard button
29. Light switch
30. Headlight remote control
31. Helmet compartment light bulb
32. License plate light bulb
33. Rear left turn indicator
34. Rear light
A. Tail light bulbs
B. Stop light bulbs
35. Rear right turn indicator
36. Front left turn indicator
37. Headlight
A. Left low-beam light bulb
B. Left high-beam light bulb
C. Tail light bulb
D. Right low-beam light bulb
E. Right high-beam light bulb
38. Front right turn indicator
39. Oil pressure sensor
40. Engine stop switch
41. Fuel level transmitter
42. MODE button
43. Instrument panel
44. Hand brake
45. External temperature sensor
46. Horn
47. Horn button
48. Horn remote control
49. Pressure sensor
50. Injection load remote control
Fuoco 500 i.e. Electrical system
ELE SYS - 3
