- Undo the screws fixing the voltage regulator to
the helmet compartment internal side.
- Undo the two screws of the saddle lock, discon-
nect the lock cables and release the sheath from
the helmet compartment.
- Undo the four screws below the gaskets in the
upper part of the compartment.
- Undo the three screws fixing it to the frame on
both sides.
Chassis Fuoco 500 i.e.
CHAS - 12
