Side fairings

COPERTURE LATERALI

Code Action Duration

1 004036 Lower chassis cover - Re-

placement

2 004129 Rear fairing - Replacement

3 004037 Side aprons-Replacement

4 004121 Fianchetto sella (1) - Sostitu-

zione

Rear cover

SCUDO POSTERIORE

Code Action Duration

1 004065 Front shield rear section - re-

moval and installation

Time Fuoco 500 i.e.

TIME - 22
