- To remove the start-up rim from the freewheel it
is necessary to turn it clockwise and pull it out.
- Remove the freewheel from the flywheel by loos-
ening the 6 fastening screws.
SINCE THE FREEWHEEL MUST BE REMOVED,
IT IS ADVISABLE TO LOOSEN THE 6 FASTEN-
ING SCREWS IN ADVANCE WITH THE FLY-
WHEEL STILL INSTALLED ON THE CRANK-
SHAFT.
- The freewheel is coupled to the flywheel with high
precision; if removal is difficult, use 2 screws as
gripping points and as removing tools, if required.
- Extract the intermediate gear provided with tor-
que limiter.
Engine Fuoco 500 i.e.
ENG - 42
