Remove the suspension tilt locking device pipes
from the headstock.
Remove first the flexible part of the calliper from
the steering tube as shown in the photograph, and
then remove the rigid part.
Remove the tone wheel wiring by disconnecting
the connector on the fuel tank after removing the
chassis central cover.
After that, remove the retainers indicated in the
figure.
Fuoco 500 i.e. Suspensions
SUSP - 7
