Stores code Description

020151Y Air heater

020193Y Oil pressure gauge

020201Y Spacer bushing driving tube

020262Y Crankcase splitting strip

020306Y Punch for assembling valve seal

rings

020329Y Mity-Vac vacuum operated

pump

020330Y Stroboscopic light for timing con-

trol

Tooling Fuoco 500 i.e.

TOOL - 4
