1: Right tone wheel
2: Left tone wheel
With interface wiring disconnected from the park-
ing electrical control unit and connected to the
system, check that the sensor resistance between
pins 23 - 17 and 24 - 17 is between 774 and 946
Ohm at a temperature of approximately 20°
Fuoco 500 i.e. Suspensions
SUSP - 39
