Stores code Description

020478Y Punch for driven pulley roller cas-

ing

020479Y Countershaft lock wrench

020480Y Petrol pressure check set

020481Y Control unit interface wiring

020482Y Engine support

020483Y 30 mm guide

Tooling Fuoco 500 i.e.

TOOL - 10
