- Inserire dove indicato le tre piastrine elastiche.

- Montare il paracolpi inferiore, avvitando le tre viti

complete di rondelle.

Smontaggio

- Svitare le tre viti complete di rondelle di fissaggio

al telaio, e recuperare il distanziale.

Chassis Fuoco 500 i.e.

CHAS - 18
