Instrument panel

GRUPPO STRUMENTI

Code Action Duration

1 005014 Odometer - Replacement

2 004099 Odometer housing - Replace-

ment

3 004035 Instrument panel - Replace-

ment

Fuoco 500 i.e. Time

TIME - 31
