FANALERIA LAMPEGGIATORI ANT

Code Action Duration

1 005067 Front direction indicator bulb

- Replacement

2 005012 Front direction indicators -

Replacement

3 005002 Front light - Replacement

4 005008 Light bulbs - Replacement

5 005139 Tail light bulb - Replacement

6 005140 Front light - Replacement

Rear lights

Fuoco 500 i.e. Time

TIME - 33
