8-5
8-5-1
8-5-2
Remote Access and Monitoring
Remote access and monitoring can be performed via RS485, RS232 or a modem (RS232).
Remote access and monitoring via RS485 and RS232 is performed using the Odyssey PC software whilst the Telemon PC
software is used in conjunction with a modem. The term PC Graphics Software is used to describe the Odyssey or
Telemon software.
The QUART (optional) is essential for the operation of remote monitoring. If the QUART is not fitted the panel will deny
access to functions 8-5-1, 8-5-2 and 8-5-3.
The remote access connection is made to the 9 pin D connector on J-NET-INT-COMS which is plugged into the J-NET-CON
on the Main Panel. There are a few types of J-NET-INT-COMS boards but the same variant can be used for direct RS232
Odyssey connection or connection to a modem.
The JUNO-NET is compatible with most RS232 modems. Modem communication is at 9600 baud, 8 bits, 1 stop bit with no
parity.
A modem is usually connected to a PC with a “null modem” cable. For connection to JUNO-NET a “straight through” or “pin
to pin” lead is required. This lead needs to be fully wired.
When the system is powered up, or a Master Reset is performed, the Main Panel looks for modem on the remote access
port. If one is found it will automatically be used for all remote monitoring.
Configure PC Graphics Software Interface
The PC Graphics Software considers a complete fire alarm system (Main Panel, Repeaters and Sub-panels) as a single
(Main) panel.
Each fire alarm system must be given a unique number between 1 and 64. This function allows you to set that ‘panel’
number.
If a panel number is not set the PC Graphics Software may not be able to monitor and access the fire alarm system.
Modem Dial Out Number
This function allows the telephone number of the remote monitoring PC to be entered. The panel will use this number to
dial out if a Fire, Fault or Pre-alarm is detected.
If a number is not entered the panel will not dial out, but a remote PC may still dial in.
The telephone number may be a maximum of 30 characters long and may include any characters that the modem
recognizes. Spaces may be used to make the number more readable. Other characters that are often used are shown on
the next lines.
P Use pulse dialing
T Use tone dialing.
@ Wait for silence for 5 seconds before dialing
, Pause for 2 seconds
For example:
T 9,,44,117 123 456
100
Manufacturers of Fire Detection Equipment
INSTALLATION & COMMISSIONING MANUAL REVISION 4.0 05/2013
JUNO NET - NETWORKABLE ADRESSABLE PANEL
