Please consult our other document entitled "LOADER SOFTWARE" for more detailed instructions.
Other Features
These are programming functions that do not fall into any other category.
Active/Installation Mode
An essential function. The system should always be left in ACTIVE mode, unless the system is being installed and
debugged.
When the system is set to Installation Mode the green SYSTEM ON LED on the front panel of the Main Panel and
Repeaters will flash.
Whilst in Installation Mode the system will automatically detect and record the presence of all connected devices and
sub-panels.
To install the system first ensure all detectors, sounders and sub-panels are connected and have power. Next select
Installation Mode using this function, exit programming mode and press SYSTEM RESET.
Once the system has been in Installation Mode for 90 seconds then the system can be put into Active Mode.
Note that there is no clear end to Installation mode because the system is constantly looking and learning. However if the
system is put into Active Mode and Installation Mode hasn’t had time to identify all system components you will very
quickly be greeted with error reports regarding the presence of unexpected devices.
If devices are ever removed, replaced or added then Installation Mode must be selected so that the system can learn the
new configuration. If you do not do this the system will report a fault.
Upload/Download Link to PC
This function cannot be accessed remotely (from a Repeater or from the PC Graphics software). Entering this function will
automatically stop all normal fire alarm system operations including communications to sub-panels and Repeaters.
It allows customer site data to be downloaded into the Customer Flash Memory.
It allows customer site data to be uploaded from the Main Panel to a PC. You may wish to do this to save the
configuration or for ease of editing. Once edited the data must be downloaded back into the panel.
To perform an upload or download you will need the correct hardware fitted to the Main Panel, a lead for connection to a
PC and the correct PC software.
Connection to a PC requires a pin-pin 9 way lead with a male D connectors at one end and a female D connector at the
other end. (Only three wires are actually necessary, so if problems are encountered it is worth trying a lead with only three
wires - Tx (pin 2), Rx (pin 3) and GND (pin5)).
The PC Loader Software
The PC Loader software is runs under Windows 7, Vista, XP. Communications to the panel is through one of the serial
communication ports (COMM PORT) and in order to install it, the only requirement is to double click on the installer
package supplied and follow the supplied instructions.
Windows COMM PORT Set-up
®
®
