Integrated Sub-panels
A Main Panel may have an Integrated Sub-panel. To enable the Integrated Sub-panel a Loopcard must be fitted to the
Main Panel PCB. The Loopcard is secured on to 4 pillars behind the LCD module.
You may fit a 1 or 3 loop Loopcard.
If the Loopcard is fitted, an ANALOGUE LOOP CONNECTION BOARD is also required. This is mounted inside the Main
Panel box and requires a cable form between it and the Main Panel PCB.
Ensure all connectors are correctly aligned.
23
Manufacturers of Fire Detection Equipment
INSTALLATION & COMMISSIONING MANUAL REVISION 4.0 05/2013
JUNO NET - NETWORKABLE ADRESSABLE PANEL
