J-NET-RS485-INT-NEW
J-NET-CON
DATA LOOPS
Main Panel RS485
NOTE:
If an external data loop is required, the main panel will need an RS485, a FIBRE OPTIC or a TCP/IP
INTERFACE BOARD fitted to the main panel Connector Board.
Make all connections with the power turned off to avoid risk of permanent damage to
the circuit boards.
28
Manufacturers of Fire Detection Equipment
INSTALLATION & COMMISSIONING MANUAL REVISION 4.0 05/2013
JUNO NET - NETWORKABLE ADRESSABLE PANEL
