GETTING A STANDARD SUB-PANEL RUNNING
If the Standard Sub-panel is fitted within the Main Panel or Repeater box and wired up correctly then the green COMMS
OK LED should be either illuminated solidly or flashing when power is applied to the Main Panel or Repeater.
If the Standard Sub-Panel is not housed within Repeater or Main Panel box then it will be necessary to apply power to the
Sub-panel.
If the COMMS OK is solid green then it is communicating correctly (via RS485 or TTL) with the Main Panel. If it is flashing
then there is no communication with the Main Panel.
The amber FAULT LED will also light if there is no communication with the Main Panel.
If the COMMS OK is permanently lit, then the Sub-panel is functional.
54
Manufacturers of Fire Detection Equipment
INSTALLATION & COMMISSIONING MANUAL REVISION 4.0 05/2013
JUNO NET - NETWORKABLE ADRESSABLE PANEL
