5-4
5-5
5-6
5-7
Inhibit I/O for Device
Allows a device to be set so that it does not operate certain I/O Groups.
The options are:
COMMON The Common I/O Group (512) is not activated when the device detects fire
ZONAL The Zone I/O Group for the device is not activated when the device detects fire
ALL No I/O Groups are activated when the device detects fire
COMMON or ZONAL inhibits will not inhibit the I/O Group directly assigned to a device (function 5-3 Assign I/O Group to
Device) if that device detects fire.
Allows you to define how an I/O module will perform when an evacuate is signaled. By default an I/O module will not
activate unless it has been assigned to an I/O Group than has been activated.
NOTE: an evacuate is not considered as an automatically detected fire event.
I/O Unit Delay or Immediate
Allows a specific I/O module to be set so that it activates immediately even if the rest of the I/O is set to be activated after
a delay.
I/O Delay Set-up
Allows the I/O (output) delay to be set. This delay applies to all I/O module outputs.
The maximum delay that is allowed is 10 minutes.
There is only one I/O timer so once it has expired events activating further delayed I/O groups will cause immediate I/O
operation.
NOTE: delays will only occur if front panel ACTIVE DELAYS button has been set to on.
NOTE: specific I/O modules (function 5-6) and specific detectors (function 6-1-6) can be set to
override this delay.
I/O Unit Action upon Evacuate
83
Manufacturers of Fire Detection Equipment
INSTALLATION & COMMISSIONING MANUAL REVISION 4.0 05/2013
JUNO NET - NETWORKABLE ADRESSABLE PANEL
