Global Fire JUNO NET - Repeater; Standard Sub-Panel

Power Budget Quiescent Condition: a - 100 mA internal circuits
b - 460 mA auxiliary supply outputs
c - 825 mA for analogue loop power
d - 1 Amp for battery charger.
Alarm Condition: 800 mA for conventional sounder circuits +a+b+c
DC Output Voltage: Maximum 27.5 V DC
Minimum 18.9 V DC
Max. Ripple Voltage: 400mV peak-to-peak @maximum output loading.
Battery Charger Output: 27.5 V DC nominal @ 20ºC
Secondary Supply: 24 V sealed lead acid batteries.
Minimum capacity 2 x 7 AH
Maximum capacity 2 x 12 AH
Both fitted internally.
Battery Fuse 3 A - 20 mm HRC
Maximum Internal Resistance 1 Ohm
Primary supply voltage: 230V +10%/ -15% VAC
EMC Standard: EN55022 class B
EN61000-4-2,3,4,5,6,8,11
EN61000-3-2,3
Secondary supply voltage: 24V DC nominal
Power supply rating: 65W or 150W
Quiescent current (without devices): 130mA
Auxiliary relay ratings: 50V AC/DC 1 Amp Resistive
Repeater outputs: Open collector 24V DC 100mA max
Dimensions: W 340mm x H 370mm x D 125mm
IR Keypad batteries: 2 x AAA
Fuses: Battery: 3A
Primary supply voltage: 230V +10%/ -15%
EMC Standard: EN55022 class B
EN61000-4-2,3,4,5,6,8,11
EN61000-3-2,3
Secondary supply voltage: 24V DC nominal
Power supply rating: 65W or 150W
Quiescent current (without devices): 80mA
Dimensions: W 340mm x H 370mm x D 125mm
Repeater
Standard Sub-panel
103
Manufacturers of Fire Detection Equipment
INSTALLATION & COMMISSIONING MANUAL REVISION 4.0 05/2013
JUNO NET - NETWORKABLE ADRESSABLE PANEL
