Global Fire JUNO NET - Typical System Schematic

TYPICAL SYSTEM SCHEMATIC
ISOOPT ZMU TMP
BGU LSM
I/O
24 V
CON
DET
EOL
4K7
ION
EOL
10K
EOL
ALL AUX RELAYS RATED AT
50V AC/DC 1 AMP RESISTIVE
12V
POWER SUPPLY
L E N
110V/230V
A.C.
REPEATER
FIRE
FAULT
PRE
ALARM
CLASS CHANGE
OR
REMOTE EVAC.
MAX CURRENT
PER LAMP
=100mA
J-NET-LPCON
J-NET-CON
LOOP 1
OUT
LOOP 2
OUT
LOOP 3
OUT
LOOP 1
RETURN
LOOP 2
RETURN
LOOP 3
RETURN
+ -+ -+ -+ -+ -+ -
AUX 1
PSU
AUX 2
PSU
BELL 1 BELL 2
24v
BATT
EVAC
ZONE
MPX
OUT PF E SF24v0v 0v
0v
+ - + - + - + - + -
PAL
NO
NO
FIR
NC
NC
NC
REPEATSAUX 2FAULT AUX 1
FLT
C
C
C
+ -
12V
+ -
+
-
+
-
CON
DET
CON
DET
ISO
SNDSNDSND
9
