J-NET-SP
Standard Sub-panels
The Standard Sub-panel addresses and detector types are set using the DIP switches on the Sub-panel.
Each Sub-panel has an 6 way DIP switch. The first 5 switches set the panel number.
Note that addresses 01 and 02 are likely to be used by Integrated Sub-panels.
1 2 3 4 5 6
ON
PANEL NUMBER
A
SUB-PANEL NUMBER SWITCHES 1- 5
1-3
4-6
7-9
10-12
13-15
16-18
19-21
22-24
25-27
28-30
31-33
34-36
37-39
40-42
43-45
46-48
49-51
52-54
55-57
58-60
61-63
64-66
67-69
70-72
73-75
76-78
79-81
82-84
85-87
88-90
91-93
94-96
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
0 0 0 0 0
1 0 0 0 0
0 1 0 0 0
1 1 0 0 0
0 0 1 0 0
1 0 1 0 0
0 1 1 0 0
1 1 1 0 0
0 0 0 1 0
1 0 0 1 0
0 1 0 1 0
1 1 0 1 0
0 0 1 1 0
1 0 1 1 0
0 1 1 1 0
1 1 1 1 0
0 0 0 0 1
1 0 0 0 1
0 1 0 0 1
1 1 0 0 1
0 0 1 0 1
1 0 1 0 1
0 1 1 0 1
1 1 1 0 1
0 0 0 1 1
1 0 0 1 1
0 1 0 1 1
1 1 0 1 1
0 0 1 1 1
1 0 1 1 1
0 1 1 1 1
1 1 1 1 1
LOOP
Nº's
LOOP
Nº's
ADDRESS ADDRESS
SWITCH SWITCH
1 2 3 4 5 1 2 3 4 5
Switch "A" is reserved
for future usage
56
Manufacturers of Fire Detection Equipment
INSTALLATION & COMMISSIONING MANUAL REVISION 4.0 05/2013
JUNO NET - NETWORKABLE ADRESSABLE PANEL
