Keys To Use Within Functions
Most functions use some or all of the following keys:
0-9 are used to input numbers
p and p are used to browse through items
B-SP (Back Space) and u are used to change fields (move the cursor)
+/- are used to select the loop
ENTER is used to select items and store changes
ESC is used to abort changes and exit
HOME is often used to go back to the start of a function
The cursor is often used to highlight the item that is being changed.
Where possible help is displayed automatically. However additional help is sometimes available if you press the help
key ‘:’ the colon.
The first press will display help for 7 seconds, a second press will ensure the help is displayed for 20 seconds. Pressing
any key whilst help is displayed will clear the help and the key press will otherwise be ignored.
The QUART (Quad Universal Asynchronous Receiver Transmitter) is an optional part that is necessary for operation of
the following:
Printer
BMS (Building Management System)
PC Graphics Software output
Modem
If the QUART is not fitted then access will automatically be denied to the programming functions that require it.
Because of the flexibility and functionality of this panel it can sometimes be quite hard to establish your desired
configuration. Zone, device and group events interact as do the various timers.
If the system does not seem to operate as intended please take your time and review the various sections in this
manual. Some settings need the front panel buttons to be activated whilst others can be inhibited for specific
devices.
The basic functionality of the panel is readily available and the fire alarm system will be operational just by supplying
it with electrical power. Exercising cause and effect capability is what this section is all about. The best way to
become familiar with all the programming facilities of this panel will be a hands-on approach aided closely by this
manual.
if a fire occurs whilst the panel is in programming mode then programming mode will
automatically be exited. If a fault occurs whilst in programming mode the fault will be reported but
it is necessary to manually exit programming mode to read the fault details on the LCD.
Help
QUART
General
NOTE:
74
Manufacturers of Fire Detection Equipment
INSTALLATION & COMMISSIONING MANUAL REVISION 4.0 05/2013
JUNO NET - NETWORKABLE ADRESSABLE PANEL
