Global Fire JUNO NET - Connection Schematic for Panel, Repeater and Sub-Panel Using Fibre Optics

MAINPANEL
EXT. SUB-PANEL
FIBRE-OPTIC
J-NET-CON
J-NET-SP
J-NET-INT-FO J-NET-INT-FO
J-NET-LPCON
35
Connection Schematic: Main Panel Repeater and Sub-Panel using Fibre Optics
Manufacturers of Fire Detection Equipment
INSTALLATION & COMMISSIONING MANUAL REVISION 4.0 05/2013
JUNO NET - NETWORKABLE ADRESSABLE PANEL
